Double Wire Chain Link Fencing Machine

Built to Outperform - For Those Who Won’t Settle for Average

As an industry pioneer in fence manufacturing automation, Secure Fencing brings you India’s only double-wire chain link machine, which is engineered for rapid output, lean operations, and world-class results. Trusted by OEMs and industry leaders, it’s the answer to expanding without sacrificing quality.

Double Wire, Triple Speed

With twin-wire feeding, you can achieve up to 5x faster production than conventional machines, without increasing the machine space and labour.

Cost-Efficient Production

Enjoy cost of production as low as ₹0.70/kg, allowing higher profitability and faster ROI for high-volume manufacturers.

Smartly Handles Raipur Wires

Smoothly runs even on slightly imperfect Raipur wires. Thanks to precision tolerance and advanced control systems.

Knuckle & Twist, Done Right

Produces fencing mesh with knuckle and twist locking styles, ensuring long-lasting joints and stronger perimeter fencing.

Plug-and-Produce

Comes fully equipped with all accessories, no extra purchases or setup hassles.

Engineered for Speed. Designed for Expansion.

Our Double Wire Chain Link Machine blends speed with durability. From infrastructure giants to rural fencing units, it’s the go-to-solution for businesses that need high performance without complexity.

Key Features:

Production Output: 200–260 kg/hr

Mesh Size Range: 40mm to 100mm

Wire Compatibility:

• GI: 2mm to 4mm
• PVC: 3mm to 5.5mm

Locking Style: Knuckle and Twist

Control System: Mitsubishi PLC + Schneider Electronics

Footprint: 20ft x 22ft

Included Accessories:

• Moulds - (30, 40, 50, 55, 60, 75, 100)MM
• Tool Kit
• Oil Dispenser
• Wheels & Spares
• Cutting Oil
• Measuring Tape
• Sensors
• SMPS
• SSR Relays
• Gloves
• Installation Guide

Applications:
Ideal for high-speed fence manufacturing for agriculture, industrial enclosures, infrastructure, solar plants, and security fencing.

Q1. What is a Double Wire Chain Link fencing Machine?

A1. It's an advanced Double Wire Chain Link Machine designed to feed two wires simultaneously—doubling production speed and achieving industrial-grade output while maintaining mesh quality.

Q2. How does the Double Die Chain Link fencing machine improve production?

A2. This Double Die Chain Link fencing machine uses twin molds to weave two wires at once, delivering up to 200–260 kg/hr—significantly faster than single-wire machines.

Q3 What are the production capacity and efficiency of the Double Wire Chain Link Machine?

A3. Secure Fencing’s variant produces 200–260 kg/hr, with the lowest production cost in India—about ₹0.70 per kg, ideal for large-scale manufacturers.

Q4 What types and sizes of wire and mesh can it handle?

A4. This Double Wire Chain Link fencing Machine supports GI wire (≈2–4 mm) and PVC-coated wire (≈3–5.5 mm), with mesh sizes ranging from 30 mm to 110 mm.

Q5. How many operators are needed to run the Double Die Chain Link fencing machine?

A5. Fully automated, it requires just one operator, enabling lean staffing and smooth operations.

Q6. What space is required for installation of this Double Wire Chain Link Machine?

A6. Compact and efficient, the machine needs approximately 20 ft x 22 ft of factory floor space.

Q7. What makes this Double Wire Chain Link fencing Machine cost-effective?

A7. By handling two wires simultaneously, it doubles output without increasing labor or footprint, allowing lower production costs and faster returns on investment.

Q8. Can this Double Die Chain Link fencing machine handle imperfect or commercial-grade wire?

A8. Yes—Secure Fencing’s model is engineered to operate smoothly even with slightly imperfect “Raipur wires,” thanks to its precision tolerances and adaptive controls.
